touchMATRIX – different models with various functions for diverse applications

The standard 186 x 64 pixel graphic display allows the variable presentation of plain text, symbols and units. By default, 28 standard units are defined, additionally customer-specific units are also freely editable. Color variants in red, green and yellow are realized by the LED backlight. With a simple parameterization by means of plain text and touchscreen, the colors can be used depending on the event (e.g. when threshold values are exceeded). Modular configuration with analog output, switch outputs, relays, serial interface (Modbus) and 115 ... 230 VAC provide maximum flexibility in connection and application.

Equipped with two 16-bit analog inputs for ± 10 V / 0 ... 10 V / 0 ... 20 mA / 4 ... 20 mA and a highly accurate 10 V reference output for potentiometers, the process indicator AX350 offers numerous functions such as tare, mean value formation, totalization, sums and difference formation as well as adjustable update time of the display. The sampling intervals can be set separately for each input. Learn more.

With 2 universal HTL inputs for encoders resp. sensors with NPN / PNP or NAMUR characteristic, an input frequency up to 250 kHz, 3 control inputs, a linearization with 24 control points and numerous functions such as scaling, filtering and start-up suppression, the DX350 is a true all-rounder. For “higher” demands the „high-end“ model DX355 offers 2 incremental HTL / RS422 / TTL inputs and a higher input frequency up to 1 MHz. Learn more.

The IX350 devices of the touchMATRIX family cover all requirements, which can be placed on SSI displays for absolute encoders. With clock frequencies up to 1 MHz, operating modes as master or slave, SSI formats binary or gray, a resolution of 13 ... 32 bit as well as applications with singleturn and multiturn encoders, these devices offer an extraordinary bandwidth. In addition, functions such as scaling and bit-blanking extended the application profile. Learn more.

All touchMATRIX devices can be freely combined with various options and their permutations. Thus each device of the predecessor series can be completely replaced by a touchMATRIX display.
