Products found: 14
Certified Safety Monitors with SinCos Encoder and Signal Splitter

DS240

Certified Safety Monitors with SinCos Encoder and Signal Splitter

Input format: SinCos (1 Vss)
Outputs: Analog (V, mA)
Outputs: 2 Relay
Outputs: 4 Transistors
  • SIL3 and PLe certification
  • Safety functions equivalent to EN 61800-5-2
    (SS1, SS2, SOS, SLS, SDl, SSM, SLI, SBC, STO, SMS)
  • 1 encoder input with format SIN+, SIN-, COS+, COS- [1 Vss]
  • 2 pulse- or control inputs with format A, B, 90°
    [HTL / PNP] (for rotary encoder, proximity switches or commands)
  • Input frequency up to 500 kHz
  • Forced-guided redundant output relay (NO)
  • 4 control outputs with push-pull characteristic, short-circuit-proof,
    [HTL], each inverse and redundant
  • Safety related 14 bit analog output for 4 ... 20 mA (scalable)
  • With signal splitter
  • Power supply 18 ... 30 V
  • Compact housing for 35 mm mounting top hat rail
    (according to EN 60715)
  • Setup via USB port by operator software or plug-in display and
    programming unit BG230 (accessories)
Safety Speed Monitor for Incremental Encoders / Sensors

DS260

Safety Speed Monitor for Incremental Encoders / Sensors

Input format: Frequency (HTL, TTL)
Outputs: Analog (V, mA)
Outputs: 2 Relay
Outputs: 4 Transistors
  • SIL3 and PLe certification (depends ofn the used encoder / sensor arrangement)
  • Safety functions equivalent to EN 61800-5-2
    (SS1, SS2, SOS, SLS, SDl, SSM, SLI, SBC, STO, SMS)
  • 1 incremental encoder input with format A, /A, B, /B, Z, /Z
    [HTL differencial, RS422]
  • 8 control inputs [HTL / PNP]
  • Input frequency up to 500 kHz
  • 2 relay outputs 5... 250 VAC / VDC (NO)
  • 4 x 2 control outputs with push-pull characteristic, short-circuit-proof,
    [HTL], antivalent or equivalent redundant or simply used
  • Safety related 14 bit analog output for 4 ... 20 mA (scalable)
  • Signal splitter
  • Power supply 18 ... 30 V
  • Wire monitoring of the sensor signals
  • Compact housing for 35 mm mounting top hat rail
    (according to EN 60715)
  • USB interface in combination with the user interface OS6.0 for the parameterization of the safety speed monitor
  • BG200 operator panel for easy parameterization and display (optional)
Safety Speed Monitor for Incremental Encoders / Sensors

DS250

Safety Speed Monitor for Incremental Encoders / Sensors

Input format: Frequency (HTL, TTL)
Outputs: Analog (V, mA)
Outputs: 2 Relay
Outputs: 4 Transistors
  • SIL3 and PLe certification
  • Safety functions equivalent to EN 61800-5-2
    (SS1, SS2, SOS, SLS, SDl, SSM, SLI, SBC, STO, SMS)
  • 2 incremental encoder inputs with format A, /A, B, /B, Z, /Z
    [HTL differencial, HTL single ended, RS422]
  • 8 control inputs [HTL / PNP]
  • Input frequency up to 500 kHz
  • 2 relay outputs 5... 250 VAC / VDC (NO)
  • 4 x 2 control outputs with push-pull characteristic, short-circuit-proof,
    [HTL], antivalent or equivalent redundant or simply used
  • Safety related 14 bit analog output for 4 ... 20 mA (scalable)
  • Signal splitter
  • Power supply 18 ... 30 V
  • Wire monitoring of the sensor signals
  • Compact housing for 35 mm mounting top hat rail
    (according to EN 60715)
  • USB interface in combination with the user interface OS6.0 for the parameterization of the safety speed monitor
  • BG200 operator panel for easy parameterization and display (optional)
Plug-in Display Unit

BG200

Plug-in Display Unit

  • Individual scalable process or speed indicator
  • Dual channel frequency indicator for visualization of the encoder frequency
  • Display of alarm and error codes
  • Touch screen with intuitive menu guidance
  • 1.54" OLED Display (128 x 64 Pixel)
  • Dimension: 50 x 80 x 15 mm (1,97 x 3,15 x  0,59")
Certified Safety Monitors with SinCos Encoder without Signal Splitter

DS246

Certified Safety Monitors with SinCos Encoder without Signal Splitter

Input format: SinCos (1 Vss)
Outputs: Analog (V, mA)
Outputs: 2 Relay
Outputs: 4 Transistors
  • SIL3 and PLe certification
  • Safety functions equivalent to EN 61800-5-2
    (SS1, SS2, SOS, SLS, SDl, SSM, SLI, SBC, STO, SMS)
  • 1 encoder input with format SIN+, SIN-, COS+, COS- [1 Vss]
  • 2 pulse inputs with format A, /A, B, /B [RS422]
  • 2 pulse- or control inputs with format A, B, 90°
    [HTL / PNP] (for rotary encoder, proximity switches or commands)
  • Input frequency up to 500 kHz
  • Forced-guided redundant output relay (NO)
  • 4 control outputs with push-pull characteristic, short-circuit-proof,
    [HTL], each inverse and redundant
  • Safety related 14 bit analog output for 4 ... 20 mA (scalable)
  • Power supply 18 ... 30 V
  • Compact housing for 35 mm mounting top hat rail
    (according to EN 60715)
  • Setup via USB port by operator software or plug-in display and
    programming unit BG230 (accessories)
Certified Safety Monitor with Multifunctional Inputs for HTL-, RS422-, SinCos-Sensors and Signal Splitter

DS230

Certified Safety Monitor with Multifunctional Inputs for HTL-, RS422-, SinCos-Sensors and Signal Splitter

Input format: Frequency (HTL, TTL)
Input format: SinCos (1 Vss)
Outputs: Analog (V, mA)
Outputs: 2 Relay
Outputs: 4 Transistors
  • SIL3 and PLe certification
  • Safety functions equivalent to EN 61800-5-2
    (SS1, SS2, SOS, SLS, SDl, SSM, SLI, SBC, STO, SMS)
  • 2 encoder inputs with format SIN+, SIN-, COS+, COS- [1 Vss]
  • 2 pulse inputs with format A, /A, B, /B [RS422]
  • 2 pulse- or control inputs with format A, B, 90° [HTL / PNP]
    (for rotary encoder, proximity switches or commands)
  • Input frequency up to 500 kHz
  • Forced-guided redundant output relay (NO)
  • 4 control outputs with push-pull characteristic, short-circuit-proof,
    [HTL], each inverse and redundant
  • Safety related 14 bit analog output for 4 ... 20 mA (scalable)
  • With signal splitter
  • Power supply 18 ... 30 V
  • Compact housing for 35 mm mounting top hat rail
  • (according to EN 60715)
  • Setup via USB port by operator software or plug-in display and
    programming unit BG230 (accessories)
Certified Safety Monitor with Multifunctional Inputs for HTL-, RS422- and SinCos-Sensors, without Signal Splitter

DS236

Certified Safety Monitor with Multifunctional Inputs for HTL-, RS422- and SinCos-Sensors, without Signal Splitter

Input format: Frequency (HTL, TTL)
Input format: SinCos (1 Vss)
Outputs: Analog (V, mA)
Outputs: 2 Relay
Outputs: 4 Transistors
  • SIL3 and PLe certification
  • Safety functions equivalent to EN 61800-5-2
    (SS1, SS2, SOS, SLS, SDl, SSM, SLI, SBC, STO, SMS)
  • 2 encoder inputs with format SIN+, SIN-, COS+, COS- [1 Vss]
  • 2 pulse inputs with format A, /A, B, /B [RS422]
  • 2 pulse- or control inputs with format A, B, 90° [HTL / PNP]
    (for rotary encoder, proximity switches or commands)
  • Input frequency up to 500 kHz
  • Forced-guided redundant output relay (NO)
  • 4 control outputs with push-pull characteristic, short-circuit-proof,
    [HTL], each inverse and redundant
  • Safety related 14 bit analog output for 4 ... 20 mA (scalable)
  • Power supply 18 ... 30 V
  • Compact housing for 35 mm mounting top hat rail
    (according to EN 60715)
  • Setup via USB port by operator software or plug-in display and
    programming unit BG230 (accessories)
Direction and Standstill Monitor

DZ210

Direction and Standstill Monitor

Input format: Frequency (HTL, TTL)
Outputs: 2 Relay
Outputs: 2 Transistoren
  • Pulse input with format A, B, 90° [HTL] or A, /A, B, /B [RS422],
    also possible for single channel
  • Input frequency up to 500 kHz
  • 2 output relays with potential-free change-over contact
    (forward, reward and zero motion)
  • 2 transistor outputs with High-Side-Driver, short-circuit-proof
  • Power supply 17 ... 30 VDC
  • Snap-on housing for top hat rail (according to EN 60715)
  • DIL switch for setup of input characteristic and definition of standstill

Speed Monitor with 3 Output Relays and Analog Output

DZ260

Speed Monitor with 3 Output Relays and Analog Output

Input format: Frequency (HTL, TTL)
Outputs: Analog (V, mA)
Outputs: 3 Relais
Outputs: RS232
  • Pulse input with format A, B, 90° [HTL] or A, /A, B, /B [RS422],
    also possible for single channel
  • Input frequency up to 1 MHz
  • 3 output relays
  • 14 Bit analog output for ±10 V or 0/4 ... 20 mA
  • Power supply 17 ... 30 VDC
  • Auxiliary voltage output +5 V for the supply of TTL encoders
  • Snap-on housing for top hat rail (according to EN 60715)
  • LCD display, backlighted
  • Setup via keys or via PC by serial RS232 interface
Speed Monitor with 3 Transistor Outputs and Analog Output

DZ261

Speed Monitor with 3 Transistor Outputs and Analog Output

Input format: Frequency (HTL, TTL)
Outputs: Analog (V, mA)
Outputs: 3 Relais
Outputs: RS232
  • Pulse input with format A, B, 90° [HTL] or A, /A, B, /B [RS422],also possible for single channel
  • Input frequency up to 1 MHz
  • 3 fast transistor switching outputs [PNP]
  • 14 bit analog output for ±10 V or 0/4 ... 20 mA
  • Power supply 17 ... 30 VDC
  • Auxiliary voltage output +5 V for the supply of TTL encoders
  • Snap-on housing for top hat rail (according to EN 60715)
  • LCD display, backlighted
  • Setup via keys or via PC by serial RS232 interface
