CA340: Fieldbus Indicator for CAN-Bus (SDO and PDO)
The simple and cost-effective display unit CA340 is used to visualize individual parameters or process data in plants that are networked via a CAN-Bus (e. g. display and specification of speed values). This "on-site" digital display is suitable for all process values available on the CAN-Bus up to 6 digits. The integrator works with both PDO and SDO objects.
- Power supply 10 ... 30 VDC
- Compact norm panel housing
- 6 digits LED display with 15 mm height
- Display range -199999 ... 999999
- DIL-switch for setup of the transmission parameters
- Dimension H x B x T = 96 x 48 x 140 mm (3.78 x 1.89 x 5.12 ")
Declaration of Conformity
File type: pdf, File size: 153 KB
File type: pdf, File size: 278 KB
Data Sheet CA306-541
File type: pdf, File size: 108 KB
CAN-Bus
EDS Files for CANopen© units MC700 / CA307 / CA340 / CA541.
